Frank CE10 Loudspeaker

Frank CE10 Loudspeaker

SKU: CE10
Categories: Short Throw

Applications of the Pearller CE10 speaker:
- Stage and event sound systems
- Auditorium sound systems
- Professional acoustic sound systems

PHYSICAL
  • Enclosure material: 15mm plywood
  • Finish: Black textured coating
  • Installation: Vertical or horizontal mounting
  • Dimensions (H × W × D): 515 × 305 × 330 mm
  • Weight: 15.32 kg per speaker
TRANSDUCERS
  • HF driver: 1.75" × 1 (CELESTION)
  • LF driver: 10" × 1
PERFORMANCE
  • System type: 10" full-range speaker
  • Frequency range: 50Hz – 20kHz ±3dB
  • Sensitivity: 106dB / 1W / 1M @ ±2dB
  • Rated power: 350W
  • Peak power: 1400W
  • Maximum SPL: 137dB
  • Impedance: 8Ω
  • Connectors (Cannon Plug): NL4 × 2
  • Coverage angle: 90 × 60 (degrees)
